Rod Ends

CCTY rod ends are available in threaded and unthreaded male/female designs.

Rod ends – or Heim Joints – are a cousin to spherical plain bearings (SPB). While SPBs provide misalignment of oscillating movement in a fixed environment, rod ends can be mounted to tie rods and other linkages to control varied movement. Rod end bearings are used in a wide variety of applications such as recreational vehicles, agricultural equipment, construction equipment and many other high performance machines.

Speak with an Engineer

Metal-to-Metal Rod Ends

GAR-DO / GIR-DO carbon steel 3 piece rod end

GAR-DO / GIR-DO

3-Piece
Steel Housing Rod End Bearing
Metric
Male Sizing Table
Female Sizing Table


POS-DF PHS-DF rod end steel bronze

POS-DF / PHS-DF

3-Piece
Steel Housing with a Bronze Liner
Metric
Male Sizing Table
Female Sizing Table

EM EF 2 piece rod end carbon steel inch

EM / EF Economy

2-Piece
Steel Housing Rod Ends
Imperial
Male Sizing Table
Female Sizing Table


MC FC 3 component rod end carbon steel

MC / FC – Precision

3-Piece
Steel Housing Rod Ends
Imperial
Male Sizing Table
Female Sizing Table

MCN FCN rod end steel with high performance polymer

MCN-Y / FCN-Y

3-Piece
Steel housing with Injected Polymer
Imperial
Male Sizing Table
Female Sizing Table

Metal-to-Polymer Rod Ends

GAR-UK GIR-UK rod end illustration steel with PTFE

GAR-UK / GIR-UK

4-Piece
Steel Housing with PTFE Fabric
Metric
Male Sizing Table
Female Sizing Table


COS-BK CHS-BK rod end steel with PTFE

COS-BK / CHS-BK

3-Piece
Steel Housing with PTFE Liner
Metric
Male Sizing Table
Female Sizing Table

COS-N CHS-N rod end steel with high performance polymer

COS-N / CHS-N

3-Piece
Steel with an Injected Polymer
Metric
Male Sizing Table
Female Sizing Table


MA FA rod end alloy steel 3 components

MA / FA – Precision

3-Piece
Hardened Steel Alloy Housing
Imperial
Male Sizing Table
Female Sizing Table
