GEZ-ES Spherical Plain Bearing (inch) I CCTY

Technical Parameter	Unit	Value
Sliding Contact Surface	–	Steel / Steel
Working Temperature	°F	-58 / +302
	°F	-22 / +266 (with seals)
Type of Lubrication	–	Grease / Oil
Seals	–	Available (2RS)
Size Range (inner dia.)	inch	½ – 7 ½

Product Number		d	D	B	C	d_m	r₁	r ₂	dyn.	stat.	α[°]	≈kg
		Dimensions							Basic load ratings		Angle	Mass
									C_r	C_0r
							min.	min.	kN	kN
GEZ 12 ES		12.7	22.225	11.1	9.525	18.3	0.15	0.6	14	41.5	6	0.022
GEZ 15 ES		15.875	26.988	13.89	11.913	22.8	0.15	1	21.6	65.5	6	0.036
GEZ 19 ES		19.05	31.75	16.662	14.275	27.4	0.3	1	31.5	93	6	0.052
GEZ 22 ES		22.225	36.513	19.431	16.662	32	0.3	1	42.5	127	6	0.085
GEZ 25 ES	GEZ 25 ES 2RS	25.4	41.275	22.225	19.05	36.5	0.6	1	56	166	6	0.13
GEZ 31 ES	GEZ 31 ES 2RS	31.75	50.8	27.762	23.8	45.6	0.6	1	86.5	260	6	0.23
GEZ 34 ES	GEZ 34 ES 2RS	34.925	55.563	30.15	26.187	49.2	0.6	1	104	310	6	0.3
GEZ 38 ES	GEZ 38 ES 2RS	38.1	61.913	33.325	28.575	54.7	0.6	1	125	375	6	0.41
GEZ 44 ES	GEZ 44 ES 2RS	44.45	71.438	38.887	33.325	63.9	0.6	1	170	510	6	0.64
GEZ 47 ES	GEZ 47 ES 2RS	47.638	90.488	50.013	42.85	82	0.6	1	280	850	6	1.63
GEZ 50 ES	GEZ 50 ES 2RS	50.8	80.963	44.45	38.1	73	0.6	1	224	670	6	0.94
GEZ 57 ES	GEZ 57 ES 2RS	57.15	90.488	50.013	42.85	82	0.6	1	280	850	6	1.6
GEZ 63 ES	GEZ 63 ES 2RS	63.5	100.013	55.55	47.625	91.2	0.6	1	345	1040	6	1.78
GEZ 69 ES	GEZ 69 ES 2RS	69.85	111.125	61.112	52.375	100.3	0.6	1	425	1270	6	2.41
GEZ 76 ES	GEZ 76 ES 2RS	76.2	120.65	66.675	57.15	109.5	0.6	1	500	1500	6	3.1
GEZ 82 ES	GEZ 82 ES 2RS	82.55	130.175	72.238	61.9	118.7	0.6	1	585	1760	6	3.8
GEZ 88 ES	GEZ 88 ES 2RS	88.9	139.7	77.775	66.675	128	0.6	1	680	2040	6	4.83
GEZ 95 ES	GEZ 95 ES 2RS	95.25	149.225	83.337	71.425	137	0.6	1	780	2360	6	5.87
GEZ 101 ES	GEZ 101 ES 2RS	101.6	158.75	88.9	76.2	146	0.6	1	900	2650	6	7.06
GEZ 114 ES	GEZ 114 ES 2RS	114 . 3	177.8	100	85.725	164.5	1	1.1	1120	3400	6	9.95
GEZ 120 ES	GEZ 120 ES 2RS	120.65	187.325	105.56	90.47	173.4	1	1.1	1250	3750	6	11.5
GEZ 127 ES	GEZ 127 ES 2RS	127	196.85	111.125	95.25	182.6	1	1.1	1400	4150	6	13.5
GEZ 152 ES	GEZ 152 ES 2RS	152.4	222.25	120.65	104.77	207.2	1	1.1	1730	5200	5	17.5
